Double click automatic cold heading machine
Source：http://m.yyoucheng.com Author：冷鐓機 Time：2014/8/18 Click：
The single double click automatic cold heading machine uses the cold heading machine method to forge optical disc elements or bar materials in the form of double clicking the whole mold. It completes the process of feeding, straightening, cutting, forming, and discharging in one machine, and is suitable for manufacturing various bolts, rivets, and other components with heads. Structural standards, beautiful and elegant appearance, easy installation
型號
|
制件桿部直徑
|
制件桿部長度
|
主滑塊行程
|
公稱壓力(KN)
|
電機(kw)
|
生產率(Pec/min)
|
重量(T)
|
Z12-16
|
12-16
|
15-150
|
200
|
1500
|
22/8
|
60
|
約14
|
Z12-16(加大)
|
12-18
|
15-150
|
200
|
1700
|
30/8
|
60
|
約16
|
Z12-16A
|
12-18
|
25-200
|
290
|
1700
|
30/8
|
50
|
約18
|
Z12-16L
|
12-18
|
45-250
|
330
|
1650
|
30/8
|
40
|
約19
|
Z12-16LL
|
12-18
|
55-300
|
420
|
1600
|
30/8
|
32
|
約23
|
Z12-20
|
12-20
|
50-300
|
430
|
3500
|
37/8
|
30
|
約30
|
Z12-20L
|
12-20
|
40-200
|
290
|
3500
|
37/8
|
35
|
約23
|
Z12-24
|
20-24
|
45-250
|
370
|
3800
|
45/8
|
35
|
約35
|
Z12-24(加大)
|
20-24
|
45-250
|
370
|
4000
|
55/8
|
35
|
約45
|
Z12-27
|
20-27
|
50-250
|
380
|
5000
|
55/8
|
35
|
約50
|
Z12-30
|
24-30
|
50-250
|
380
|
6000
|
75/8
|
35
|
約56
|
